Products Available　

IP Rating

UKF1-20

20A 250V Single pole surface switch

66

Terminals accommodate 16mm2 cables. M rating 220.

UKF1-35

35/63A 250V Single pole.

66

UKF1-63

Terminals accommodate 16mm2 cables. M rating 220.

UKF2-20

20A 440V double pole.

66

Terminals accommodate 16mm2 cables. M rating 180.

UKF2-35

35A 440V double pole.

66

Terminals accommodate 16mm2 cables. M rating 180.

UKF2-63

63A 440V double pole.

66

Terminals accommodate 16mm2 cables. M rating 160.

UKF3-20

20A 440V triple pole.

66

Terminals accommodate 16mm2 cables. M rating 180.

UKF3-35

35A 440V triple pole.

66

Terminals accommodate 16mm2 cables. M rating 180.

UKF3-63

55A 440V triple pole.

66

Terminals accommodate 16mm2 cables. M rating 160.

UKF4-20

20A 440V triple pole.

66

Terminals accommodate 16mm2 cables. M rating 180.

UKF4-35

35A 440V triple pole.

66

Terminals accommodate 16mm2 cables. M rating 180.

UKF4-63

55A 440V triple pole.

66

Terminals accommodate 16mm2 cables. M rating 160.

UKF3-55-32CE

55A 440V triple pole. With 32mm conduct entry at each end.

66

Terminals accommodate 16mm2 cables. M rating 160.

UKF3-63-32CE

63A 440V triple pole. With 32mm conduct entry at each end.

66

Terminals accommodate 16mm2 cables. M rating 160.

UKF3-80-CE

80A 440V triple pole. With 32mm conductt entry at each end.

66

Terminals accommodate 16mm2 cables. M rating 150.
