GTH Thermal Relay

Price：Members-only access to
Documentation.:      Download

GTH series thermal overload relay are suitable for overload and phase-failure protection of AC
motors with frequency of 50/60Hz,voltage up to 690v,current up to 0.1-85A under 8-hours duty
or uninterrupted duty.
Functions provided by these relays, are phase-failure protection, temperature compensation, ON/
OFF indication, Stop button, Test button and manual/automatic reset.
Applicable Standards
National Standard: GB 14048
International Standard: IEC 60947-4-1
The relays can be mounted onto contactors or installed as single units.
